DJI Matrice 200 Series

**PRICE ON APPLICATION - PLEASE CONTACT US FOR QUOTE**

The DJI Matrice 200 is a rugged drone that has been built to handle nearly any survey or inspection task. High-performance motors paired with 17-inch propellers ensure stable flight in strong winds.

The new dual-battery power system automatically heats batteries when flying in sub-zero temperatures, while an enclosed design ensures weather and water resistance, so you can fly in a wide range of environments.

The M200 Series drones fold down in a snap and unfold just as quickly. Gimbal mounting plates and aircraft arms stay mounted during transportation so that you’re ready to fly within minutes.

APPLICATIONS

Power Line Inspection

With improved reliability and precisions, inspectors are empowered to visualize extensive powerline networks with unparalleled detail despite adverse conditions.

Search and Rescue

Equipped with both an aerial zoom and thermal camera, first responders can now quickly locate missing people in remote areas and plan the safest approach path.

Wind Turbine Inspection

With improved flight stability in windy conditions and a top-mounted gimbal, turbine inspectors can spot millimeter-sized damage along all parts of a turbine’s propellers.

Bridge Inspection

With a top-mounted gimbal pilots can fully inspect bridges, allowing teams to adequately plan maintenance schedules for improved public safety and minimized costs.

Video of the DJI Matrice 200

---

M200

Aircraft

Package Dimensions	31.1×15.4×11.4inch (790×390×290mm)
Dimensions (unfolded)	28.2×8.7×9.3 inch (716×220×236 mm)
Dimensions (folded)	34.9×34.6×14.9 inch (887×880×378 mm)
Folding Method	Folded Inward
Diagonal Wheelbase	25.3 inch (643 mm)
Number of Batteries	2
Weight (TB50)	Approx. 3.80 kg
Weight (TB55)	Approx. 4.53 kg
Max Takeoff Weight	6.14KG
Max Payload (2 TB50)	Approx.2.34kg (with two standard batteries )
Max Payload (2 TB55)	Approx.1.61kg (with two standard batteries )
Max Ascent Speed	16.4 ft/s (5 m/s)
Max Descent Speed	Vertical: 9.8 ft/s (3 m/s)
Max Speed	S Mode 23m/s P Mode 17m/s A Mode 23m/s
Max Service Ceiling Above Sea Level	1.55 mi (2500 m)
Max Wind Resistance	32.8 ft/s (10 m/s)
Max Flight Time(No Payload, with TB50)	27min
Max Flight Time(No Payload, with TB55)	38min
Max Flight Time(Full Payload, with TB50)	13min
Max Flight Time(Full Payload, with TB55)	24min
Motor Model	DJI 3515
Propeller Model	1760S
Retractable Landing Gear	Standard
Operating Temperature	-4° to 113° F (-20° to 45° C)
IP Rating	IP43
Compatible Gimbals	Zenmuse X4S Zenmuse X5S Zenmuse Z30 Zenmuse XT
